JMC-011 Ceramic fiber board

Producing Technology:   All kinds of ceramic fibre boards,adopting corresponding blowingfibre(ST.HP.HAA.HZ)  as the material,are produced by vacuum formed technology.   All kinds of ceramic fibre boards,do not only possess the same;function of fibre,but also have hard texture,excellent toughness and intensity,and excellent fire resistant and heat preservation.

Working Technology:   Working Temperature is determined by using condition,heating manners and environment atmosphere,etc.

Characteristics: low thermal conductivity and low heat storage excellent thermal stability and thermal shock resistance. excellent toughness

Usage:   liners of industrial furnace   high temperature liner,vehicle,baffle of furnace door,disjunctive board of temperature   high temperature equipment insulation,heat preservation.   space navigation,ship building,heat insulation fireproofing,sound insulation,insulation

Item Product		COM	ST	HP	HAA	HZ
Specification Tem(℃)		1100	1260	1260	1360	1430
Working Tom(℃)		＜1000	1050	1100	1200	1350
Colour		White	White	White	White	White
Density(kg/m3)		260 320	260 320	260 320	260 320	260 320
Rate of line(%) (24h,Density320kg/m3)		-4 (1000℃)	-4 (1000℃)	-4 (1100℃)	-4 (1200℃)	-4 (1350℃)
Rate of thermal conductivity(w/m.k) (Density 285kg/m3)		0.085(400℃) 0.132(800℃) 0.180(1000℃)	0.085(400℃) 0.132(800℃) 0.180(1000℃)	0.085(400℃) 0.132(800℃) 0.180(1000℃)	0.085(400℃) 0.132(800℃) 0.180(1000℃)	0.085(400℃) 0.132(800℃) 0.180(1000℃)
Tensilestrengty(Mpa) (strength10%)		0.5	0.5	0.5	0.5	0.5
Chemical composi-tion (%)	AL2O3	40-44	45-46	47-49	52-55	39-40
	AL203+SIO2	95-96	96-97	98-99	99	-
	AL2O3+SIO2+Zro2	-	-	-	-	99
	Zro2	-	-	-	-	15-17
	Fe2O3	<1.2	<1.0	0.2	0.2	0.2
	Na2O+K2O	≤0.5	≤0.5	0.2	0.2	0.2
Size(mm)		Common spectification:600*400*10-5；900*600*20-50 other made according to customer's requirements
